Charging Nikon DSLR batteries in your car with 12V power

megaadmin — Wed, 22 May 2019 19:59:24 +0000

If you travel frequently by car or mobile home and also want to charge your batteries on the road, you may know the problem: Sometimes there is no 220V power supply at hand and the battery of the SLR remains empty.
After a long search, I have now found a charger that charges the batteries on the 12V on-board power supply, for example via the cigarette lighter.

I have been a fan of the third market batteries of “Blumax” for quite some time, as I report in this blog entry. The same manufacturer also offers a selection of chargers, one of them can also charge the batteries on the 12V car electrical system.

In the past, I have searched several times for possibilities to charge the batteries, such as the EN-EL15a or EN-EL15b mobile, but have always failed, because the tried chargers functioned unreliably. Now I have made another attempt and I am finally satisfied with my new 12V charger.

Blumax Akku kompatibel mit Nikon EN-EL15 [ 2040mAh ] + LCD Dual Charger EN-EL15c EN-EL15b EN-EL15a für D800 D850 D7200 D7500 Z8...*

ERSETZT FOLGENDE AKKUS: Nikon EN-EL15 / EN-EL15a / EN-EL15b / EN-EL15c
KOMPATIBEL MIT: Nikon Zf - Z8 - Z7 II - Z7 - Z6 II - Z6 - Z5 --- D500 - D600 - D610 - D750 - D780 - D800 - D800E - D810 - D810A - D850...

My new “Blumax” charger is not very light and space-saving (12.5cm X 11cm X 4cm at 284gr weight), but it can charge two of the above batteries at the same time.

The charger can charge the batteries either via the regular 220V power supply or the 12V car electrical system. The variety of the connection possibilities relativizes the bulky form and the high weight of the charger, as now I don’t have to carry the original chargers with me anymore. An output socket for USB power allows me furthermore to charge my power bank connected via USB.

The device has a digital display, which shows the state of charge of the batteries in percentages of 10 (10%, 20%, 30%, …, 100%). This display of the state of charge works reliably, the value actually corresponds to a large extent with the value determined by the camera. The devices I have tried so far could only do this very unreliably or not at all.

When charging the batteries, the user has the choice of whether they should be charged particularly quickly or with normal charging current. I myself always use the slow mode, because I think that the batteries are charged slower, but more gently. So I haven’t gained any experience with the fast mode yet.

Ihre Daten werden erst beim Abspielen des Youtube-Videos an den Dienst übermittelt. Your data will only be transmitted to the service when you play the Youtube video.

My first choice as a Lightroom alternative

I’m gonna do some advertising. I’ve been dealing with all kinds of image editing software for months, comparing a lot, testing a lot and finally choosing RAW developer and Lightroom alternative Luminar 3.

Have a look and try the free trial version. Just click on the banner:

All the links in this text are Amazon Affiliate Links, and by clicking on an affiliate link I will earn a percentage of your subsequent Amazon purchases. However, this circumstance does not influence the background of my product recommendation. This product recommendation is independent, honest and sincere.

Bei allen genannten Links handelt es sich um Amazon-Affiliate-Links. Durch einen Klick auf einen Affiliate-Link werde ich prozentual an Euren darauf folgenden Amazon-Einkäufen beteiligt. Dieser Umstand beeinflusst aber nicht die Hintergründe meiner Produktempfehlung. Diese Produktempfehlung erfolgt unabhängig, ehrlich und aufrichtig.

Der Beitrag Charging Nikon DSLR batteries in your car with 12V power erschien zuerst auf Pixelfriedhof.

Nikon D500 4K Video Settings – Best practise explained step by step

megaadmin — Thu, 16 May 2019 19:01:26 +0000

In this manual I will explain the settings I use to record videos on the Nikon D500 and why I use these settings. So you can create clear video with high recording quality with your D500.

The complete manual as video

Reading’s not your style? Here you see all settings with explanation in the video.

Ihre Daten werden erst beim Abspielen des Youtube-Videos an den Dienst übermittelt. Your data will only be transmitted to the service when you play the Youtube video.

Setting the Camera to M Mode

This mode gives us full control over both exposure time and aperture.

Choosing the right shutter speed

When creating videos, the shutter speed must always be set in proportion to the video material being made and its frame rate.
As exposure time I use 1/60, because I usually shoot videos later with 30 frames per second (30p), more about that later.
If you use other frame rates, like 60p, 50p, 30p, 25p or 24p, you have to adjust the shutter speed to the next suitable value. Here again the overview:

Framerate	Shutter speed
60p	1/125s, as there is no 1/120s
50p	1/100s
30p	1/60s
25p	1/50s
24p	1/50, as there is no 1/48s

Attention: Please also note the section “Flicker reduction” in this context.

Choosing the right aperture

Which aperture you choose is up to you, depending on how you want to present your motif. If you choose a lower aperture, the background of your motif will blur due to the shallow depth of field, making your motif more prominent.

With a higher aperture, the background of your motif is sharper due to the high depth of field and the entire image is characterized by a high depth of detail due to continuous sharpness.
Note that if you choose a higher aperture, the image itself becomes darker, and if you choose a lower aperture, the image becomes brighter.

The only important thing at this point is that we have control over the aperture, because we use the M mode of our camera to do this. If we were to let the camera control the aperture in A mode, the camera would change the aperture depending on the light situation while shooting and we would take a shot with varying depth of field and brightness all the time. Not only does this look unprofessional, it’s also really annoying for the viewer.

Movie Shooting Menu Settings

For all the following settings, we switch to the movie recording menu. The settings stored there only take effect when we operate the camera in movie mode. I don’t proceed here in the order of the menu entries, as for example some settings are already adjusted automatically by the selection of the resolution and frame rate and we don’t have to deal with them anymore.

Choosing the correct frame size/frame rate

I make my own video recordings in 4k with 30 frames per second.
At 30 frames per second, movements in the picture look most natural and smooth, and 60p shots of action cams can be integrated very easily, for example to create slow-motion functions.

Therefore, I first select the setting “3840 x 2160; 30p” in the film recording menu under “Frame size/frame rate”.
With these settings, the “Choose image area” is changed to “DX” by default, the movie quality is thus automatically set to “High” and the digital VR is off, so we don’t need to deal with these menu items anymore.

Note: To be honest, nobody buys a Nikon D500 or D7500 to make bad videos, I myself never understood why there is the possibility to set the movie quality to “Low” at all.

ISO sensitivity settings

Now you can decide how you want to proceed and whether you want to make the ISO settings manually or automatically. In the menu entry “IOS Sensitivity Settings” you can select if the automatic should be used in the field “Auto ISO control (Mode M)”.

• If you are recording a video in an environment where the lighting conditions in the subject will not change, you can manually adjust the ISO settings and then leave them at the correct value.
• If you have to assume that lighting conditions will change during shooting, for example because a person moves in the picture and their illumination varies, use the ISO automatic.
• If you are simply lazy, regardless of the ambient light conditions, you also use the ISO automatic. Seriously, ISO auto works reliably and doesn’t cause any image distortion if the ISO number changes during shooting. Actually, you can use the ISO automatic with a clear conscience.

There is one thing that needs to be considered with regard to the ISO automatic. Set the “Maximum sensitivity” value to “10,000”. Above this value, the image quality can suffer from noise and color noise, so we only allow the ISO automatic to operate up to this value.

White balance

Almost the same applies here as with the ISO automatic.
Actually, the automatic white balance is sufficiently reliable. I use it in 90% of all shots.

Picture Control

Here I select the setting “FL Flat”.
This preserves details over a wide range of tonal values, which maximizes the optimization potential in later post-processing, i.e. you can get the most out of this profile afterwards.

Active D-Lighting

Off. I don’t want the camera to manipulate the image independently.

High ISO NR

Here we leave the default value “Normal” set.

Flicker reduction

The flicker reduction is intended to avoid flickering in the image, which can be caused by artificial lighting. Depending on the frequency at which the local power grid operates (50Hz in Germany), some light sources tend to emitt the normal fluctuations in the power grid, so that you will notice them when recording video at that light.

The automatic flicker reduction delivers good results. Sometimes, however, it also fails, this can happen in very bright environments, for example.
To counteract this, you can take the following measures:

Manual setting of the flicker reduction to 50Hz or 60Hz, depending on which setting gives the best result.
If the flicker reduction is not enough, you may need to adjust the shutter speed, even if this would violate the above recommended shutter speeds.
o1/125s, 1/60s or 1/30s at 60Hz power grid
o 1/100s, 1/50s or 1/25s at 50Hz power grid

Microphone sensitivity

When I use the built-in microphone of the D500, I use the automatic level.
If I use an external microphone such as my Zoom H2n, I manually level the microphone input.
You can find more details about external microphones in this blog post “Zoom H2n as an external microphone on the DSLR”.

Frequency response

Here you can choose between “Wide” and “Voice”. I personally don’t like the sound of the “Voice” setting in speech at all and therefore use the much more natural sounding “Wide” frequency response, no matter if I record with the built-in microphone of the D500 or my Zoom H2n as an external microphone. You can find more details about external microphones in this blog post “Zoom H2n as an external microphone on the DSLR”.

Wind noise reduction

The wind noise reduction settings only work when we use the D500’s built-in microphone.

If I record in locked, windless rooms, I switch off wind noise reduction as a potential source of error.
If I record outside with the built-in microphone, I activate wind noise reduction.

Which memory card is suitable for 4k video?

So that your camera can pack even high data rates quickly on the memory card, you should rely on a correspondingly fast SD or XQD card.
You don’t have to buy the expensive XQD cards, even a fast SDXC card is sufficient.

I myself use the following card:

SanDisk Extreme PRO 128GB SDXC Memory Card up to 170MB/s, UHS-1, Class 10, U3, V30*

Professionelle Leistung für schnelle Aufnahmen und 4K UHD Videos mit der SanDisk Speicherkarte; Im Lieferumfang inbegriffen ist die...
Dank der schnellen Übertragung von bis zu 170 MB/s warten Sie nicht mehr lange, während Ihre Bilder und Videos auf Ihre SD Karte oder...

Record video – what do I have to do?

Now it’s getting easy. At the bottom right of the display you will find a toggle switch with a photo and a video symbol. Toggles this switch so that the video mode is active. Now switch on Live-View and you will see the camera’s field of view in 4K mode on the display. By pressing the red “Record” button on the left under the release button, you start and stop the recording.

My first choice as a Lightroom alternative

Have a look and try the free trial version. Just click on the banner:

Der Beitrag Nikon D500 4K Video Settings – Best practise explained step by step erschien zuerst auf Pixelfriedhof.

Nikon D500 after firmware update 1.20 with fully functional WiFi

megaadmin — Mon, 29 Apr 2019 18:22:29 +0000

Nikon has released the firmware update of version 1.20.

After installing the update on my camera, I couldn’t believe my eyes.
Apparently Nikon finally gave the D500 the long-awaited open Wi-Fi, with which now also connections to other devices than only the SnapBridge app are possible.

In the release notes of the 1.20 firmware update, however, there are no references to this change, only support for the SnapBridge app is mentioned here:

But in fact, after the camera has been updated to the new firmware, we can find the data of the WLAN network that the D500 is using in the menu under “System” “Wi-Fi” “Establish Wi-Fi connection”. With this data, we can now dial into the camera’s network using a PC, Mac or mobile device and then remotely control it using any software such as “qdslrdashboard” or “ControlMyCamera”.

The new firmware 1.20 is available at this link: https://downloadcenter.nikonimglib.com/en/download/fw/323.html

Neewer 2er Pack 750II TTL Blitz Speedlite Kit mit 2.4G Wireless Trigger und Diffusor, Kompatibel mit Nikon DSLR DSLR D850 D810...*

BLITZMODI: High Guide Nr. 58 (ISO 100, 180mm), Unterstützt TTL, Manuell, Multi, S1-, S2-Modus, Wiederaufladezeit: ca. 3,5s, Drehung um...
KOMPATIBILITÄT: Kompatibel mit Nikon D810 D800 D750 D700 D7500 D7200 D7100 D7000 D610 D600 D500 D5500 D5300 D5200 D5100 D5000 D3300...

See the new Wi-Fi functions in a video:

Ihre Daten werden erst beim Abspielen des Youtube-Videos an den Dienst übermittelt. Your data will only be transmitted to the service when you play the Youtube video.

Further links to software for remote controlling your D500

https://dslrdashboard.info

https://itunes.apple.com/de/app/controlmycamera/id1444319448?mt=8

Special offer

Beschoi Fotorucksack wasserdicht Kameratasche Kamerarucksack mit Laptopfach für Canon Sony Nikon Olympus SLR/DSLR Kamera,...*

Dieser Kamera Rucksack geeignet für DSLR Kamera mit aufgesetztem Objektiv bis 320mm, 4-6 weitere Objektive, Blitzgerät, Zubehör, 14...
Außenmaße: 44cm*28cm*14cm; Innenmaße: 41cm*27cm*13.5cm. Robust und wasserabweisend, zweifarbiges Nylon-Material

My first choice as a Lightroom alternative

Have a look and try the free trial version. Just click on the banner:

Der Beitrag Nikon D500 after firmware update 1.20 with fully functional WiFi erschien zuerst auf Pixelfriedhof.

Set up Nikon D500 for bracketed exposure series for HDR

megaadmin — Sun, 29 Oct 2017 14:46:39 +0000

In this video I’ll show you how to set up the Nikon D500 to create an exposure bracket for HDR shots. We store all HDR-specific settings in a separate user setting under the photo and individual settings, so that we can quickly switch between normal workflow and HDR workflow.

Nikon D500 kaufen -> http://amzn.to/2zYOcVR (Amazon Affiliate-Link)

Here is the video showing the correct settings:

Ihre Daten werden erst beim Abspielen des Youtube-Videos an den Dienst übermittelt. Your data will only be transmitted to the service when you play the Youtube video.

And here again the menu settings in text form:

Selecting the correct operating mode

First of all we make sure that we operate the camera in mode “A“.

Photo Shooting -> Create new photo shooting menu bank for HDR

Photo Shooting Settings

Change Storage folder name to HDRD5 for example – (so we have our own directory for HDR photos)
Change file naming to HDR for example – (so we can distinguish HDR-photos already at the filename from “regular” photos)
Picture Quality RAW
Imagesize L
NEF RAW, lossless compression with 14-bit
ISO-Auto OFF, start at 100
White balance Cloudy
Active D-Lighting OFF
Noise Reduction with Long Time Exposure OFF
Vignetting Correction OFF
Auto distortion control OFF
flicker reduction OFF
Auto bracketing set AE

Custom settings -> Create new custom settings bank for HDR

Custom configuration settings

C – Timers/AE lock -> C3 Self-timer -> Self-timer delay 2
C – Timers/AE lock -> C3 Self-timer -> Number of shots = 5
Interval between shots 0.5 seconds

Enable exposure bracketing before shooting

Hold down the BKT button and use the rear dial to set 5F for exposure bracketing with 5 levels. 1.0 select for whole step size.

Switch to self-timer, and take pictures. Now 5 shots are taken automatically within the configured exposure bracket with a lead time of 2 seconds.

After the end of the HDR shooting

Photo capture configuration back to standard configuration
Individual configuration back to standard configuration
Hold down the BKT button and use the rear mode dial to set 0F for deactivated bracketing.

How to develop the HDR photo / Which Software to use

As a software for HDR merging I use Aurora HDR 2019.
You can get yourself a free trial by clicking this link: https://skylum.grsm.io/ENAuroraYT
